John Deere 9760 Sts 9860 Sts Combine Repair Manual

Description

John Deere 9760 Sts 9860 Sts Combine Repair Manual

John Deere For complete service information, also see: 9560 STS, 9660 STS, 9760 STS and 9860

STS Combines

Diagnosis and Tests . . . TM2182

Alternators and Starting Motors

POWERTECH 4.5 L & 6.8 L Diesel CTM77

Engines—Base Engines . . .CTM104

POWERTECH 6.8 L Diesel Engine—Level 14

Diagnostics – Electronic Fuel Systems with

Denso HPCR . . . CTM320

POWERTECH 8.1 L Diesel Engines—Base

Engine . . . CTM86

POWERTECH 8.1 L Engines—Level 9

Electronic Fuel Systems with Denso In-Line

Pump . . . CTM255

POWERTECH 9.0 L Tier 3/Stage IIIA OEM

Diesel Engines—Base Engine . . .CTM400

POWERTECH 9.0 L Diesel Engine—Level 14

Diagnostics – Electronic Fuel Systems with

Denso HPCR . . . CTM385

POWERTECH 10.5 L and 12.5 L Diesel

Engines—Base Engine . . . CTM100

POWERTECH 10.5 L & 12.5 L Diesel

Engines—Operation and Diagnostics for

Deere Level 6 ECU . . .CTM188

100 Series Hydraulic Cylinders . . . TMH100A

SECTION 10—General

16—Hydraulic Valve Stack (S.N. —715300)
05—Safety
17—Hydraulic Valve Stack (S.N. 715301—)
10—Specifications
20—Hydraulic Cylinders
15—Tune-Up and Adjustment
25—Motors
20—Fuels and Lubricants
30—Accumulator

John Deere 9760 Sts 9860 Sts Combine Repair Manual

SECTION 20—Engine
SECTION 80—Separator Shell
05—Remove and Install Engine
05—Gull Wing Doors
10—Cooling System
15—Lower Engine Repair

SECTION 90—Operator Station Repair

SECTION 30—Fuel and Air Repair

05—Air Conditioning System (R134a)
05—Air Intake System
10—System Components
10—Diesel Fuel System
15—Cab

SECTION 40—Electrical System

SECTION 110—Feeder House Repair
05—Batteries
05—Conveyor
10—Harness and Connector Repair
10—Top Shaft and Slip Clutch
15—Wire Harness Routing
15—Feeder House Drives and Reverser
20—Fuses, Circuit Breakers and Relays
Gear Case
25—Lighting
20—CONTOUR MASTER Tilt Cylinder
30—Operators Station
25—CONTOUR MASTER Tilt Frame
35—Sensors and Switches
40—Wiper

SECTION 120—Separator
45—Alternator
05—Separator Repair
50—Starting Motor
10—Separator Drives
55—Electrical Engine Control
15—Residue Disposal
60—GREENSTAR Components
20—Conveyor Augers, Cleaning Fan And
Chaffer And Sieve Frame

SECTION 50—Power Train Repair
25—Tailings Elevator and Augers
05—Transmission and Differential
30—Primary Countershaft Gear Case
10—Single Reduction Final Drive—Heavy
35—Header Electromagnetic Clutch
Duty
15—Hydrostatic System

SECTION 130—Grain Tank and Unloading System
20—Cam Lobe Motor Repair
25—Tires and Wheels
05—Grain Tank Cross Augers
10—Unloading Auger System Drives

SECTION 60—Power Steering and Brakes
15—Vertical Unloading Auger and Lower
05—Steering
Gear Case
10—Brakes
20—Horizontal Unloading Auger and Gear Case

SECTION 70—Hydraulic Repair
25—Clean Grain Elevator 05—Hydraulic Reservoir
30—Grain Tank and Extensions 10—Hydraulic Pumps
